CHEMICAL PROCESSING

Applications

  • Single point reactors
  • Vent condensers
  • Dryers
  • Belt Cooling Systems (Rotoformers, Flaking Systems, Granulation Systems, Film Casting)

Equipment

  • Low temperature single stage chillers (+20*F to -40*F)
  • Two stage chillers (-45*F to -60*F)
  • Ultra Low Temperature Cascade chillers (-60*F to -90*F)
  • Temperature Control Modules  – Combination Systems High Heat, Ultra Low Temperature (+400°F to -60°F)
  • High Temperature Heating Thermal Fluid Systems (300°F to 650°F)
Chemical Processing
Pharmaceutical Processing

PHARMACEUTICAL PROCESSING

Applications

  • Single point reactors (Jacket Cooling)
  • Reactor trains (50 gallons to 5000 gallons)
  • Vent condensers
  • Lyophillizers
  • Extraction
  • Cold Storage

Equipment

  • Low Temperature Single Stage Chillers (+20°F to -40°F)
  • Two Stage Chillers (-45°F to -60°F)
  • Ultra Low Temperature Cascade Chillers (-60°F to -90°F)
  • Temperature Control Modules –  Combination Systems High Heat, Ultra Low Temperature (+400°F to -60°F)

RUBBER MIXING & COMPOUNDING

Applications

  • Mixers
    • Banbury type mixers
    • Tilt Mixers
  • Mills
  • Calendar
  • Extrusion
  • Tire Manufacturing
  • Industrial Rubber Products
  • Polymer Products

Equipment

  • X Series Mixer TCU with 2 or 3 Zones (50°F to 250°F)
  • Y Series Mill TCU with 2 Zones (50°F to 250°F)
  • Z Series Multi-Zone Extruder TCU (50°F to 250°F)
Rubber Processing
Food Processing

FOOD PROCESSING

Applications

  • Dough Mixing
  • Cold Storage
    • +34°F to +50°F (Coolers)
    • -20°F to +10°F (Freezers)
  • Spiral Freezing & Tunnel Freezing
  • Flash Freezing
  • Falling Film Chillers
  • Evaporation
  • Extraction
  • Mixing/Blending
  • Homogenation / Pasteurization
  • Pastillation

Equipment

  • Low temperature single stage chillers (+20*F to -40*F)
  • Two stage chillers (-45*F to -60*F)
  • Ultra Low Temperature Cascade chillers (-60*F to -90*F)

COLD STORAGE REFRIGERATION

Applications

  • Pharmaceutical Storage
  • Food & Beverage Storage
    • Cooler Chillers require around 34°F to 50°F of cooling
    • Freezer Chillers require around -20°F to +10°F for storage until truck loading

Equipment

  • Low Temperature Single Stage Chillers (+20°F to -40°F)
  • Two Stage Chillers (-45°F to -60°F)
  • Ultra-Low Temperature Cascade Chillers (-60°F to -90°F)

Typical Food Storage End Products

  • Dairy
  • Cheese and Whey
  • Prepared Foods
  • Frozen Foods
  • Bread Products
  • Beverage – Juice, Soft Drink, Health Drinks
  • Ice Cream
Cold Storage
Research and Development Testing

R&D TESTING LABS

Applications

  • Aerospace (Jet Engine Testing)
  • Automotive (Drive Train Testing, Heat/Cool Cycling)
  • Food Processing (Small Production Testing)
  • Pharmaceutical Processing (Small Production Testing)
  • Rubber Processing (Lab Mill, Mixer, and Extrusion)

Equipment

  • Low Temperature Single Stage Chillers (+20°F to -40°F)
  • Two Stage Chillers (-45°F to -60°F)
  • Ultra Low Temperature Cascade Chillers (-60°F to -90°F)
  • Chiller/Heating Systems with wide temperature range (-40°F to -400°F)

OIL AND GAS PROCESSING

Applications

Upstream

  • Refrigeration solutions for Onshore/Offshore production
  • Gas Dew Point control by refrigeration
  • Hydrocarbons recovery

Midstream

  • Refrigeration in Natural gas processing
  • Gas to Liquid applications
  • Vapor recovery units (VRU)
  • Boil Off Gas recovery
  • Loading/Unloading Refrigeration
  • Small scale LNG liquefaction

Downstream

  • Process cooling
  • Hydrocarbons cooling
  • Mixed hydrocarbon, compression & liquefaction
  • CO2 processing
  • Gas liquefaction
  • Light ends separation
  • LPG and condensate recovery by turboexpander
  • De-ethanizer condenser refrigeration
  • Flare gas/vent/vapor recovery
  • Chemical reaction temperature control
  • Nitrogen chilling Gasoline fractionation
  • Utility cooling (chilled water, chilled glycol)
  • Fertilizers plant, Ammonia BOG & Ammonia
    refrigeration system

Equipment

  • Low Temperature Single Stage Chillers (+20°F to -40°F)
  • Two Stage Chillers (-45°F to -60°F)
  • Ultra Low Temperature Cascade Chillers (- 60°F to -90°F)
  • Temperature Control Modules Combination Systems High Heat, Ultra Low Temperature (+400°F to -60°F)
  • High Temperature Heating Thermal Fluid Systems (300°F to 650°F)

Refrigerant Types

  • Freon – R-134a, R-507
  • Ammonia – R-717
  • Hydrocarbons
  • Propane – R290
  • Ethane – R170
  • Propylene – R-1270
  • Butane – R600
  • CO2 – R-744
Oil and Gas Processing
Ice Rink and Arena

ICE RINKS & ARENAS

Applications

  • Single Standard Sheet (85’ x 200’) = 100 tons of refrigeration
  • Single Olympic Sheet (98.4’ x 197’) = 125 tons of refrigeration
  • Double Standard Sheet (2 @ 85’ x 200’) = 200 tons of refrigeration
  • Year Round
  • Seasonal
  • Indoor Arenas
  • Outdoor Rinks

Equipment

  • Refrigerant
    • R-507 HFC
    • R-717 Ammonia
  • Compressors
    • Open drive reciprocating
    • Open drive twin screw
    • Open drive single screw
    • Semi-hermetic twin screw
    • Semi-hermetic reciprocating
  • Evaporator
    • Direct Expansion
    • Flooded
  • Condenser
    • Evaporative Cooler
    • Air cooled
    • Water cooled

APPLICATION CONFIGURATOR


Please select system type below:


COOLING CAPACITY (Tons)

HEATING CAPACITY (kW)

TEMPERATURE RANGE

°C°F

COOLING CAPACITY (Tons)

TEMPERATURE RANGE

°C°F

HEATING CAPACITY (kW)

TEMPERATURE RANGE

°C°F

HEATING CAPACITY (kW)

TEMPERATURE RANGE

°C°F

What We Do - Custom Engineered Industrial Chillers and TCUs

E3 ICE Logo

We Specialize in Low & Ultra-Low Temperature Chillers
Low Temperature Chillers: 20F to -20F
Ultra-Low Temperature Chillers: -20F to -100F or below
Unit Types: Single Stage, Two-Stage, or Cascade
Capacity: 5-tons up to 850-tons
Refrigerants: HFCs, Ammonia, CO2, Propane
Compressors: Screw or Reciprocating
Compressor Motors: Semi-Hermetic, Hermetic, or Open Drive
Condensers: Water, Air, or Evaporative Cooled
Evaporation: Flooded or Direct Expansion
Controls: PLC-based Systems

E3 TCU Logo

Hot Water Temperature Control Units
– Threaded or welded piping construction
– Long or close coupled pumps available in vertical or horizontal orientation
– Steam or Electric Immersion Heating Options
– Configuration Options include: Vertically Stacked, Portable, Single, or Multi-Zoned Skids

Hot Oil Temperature Control Units
– Extreme temperature heat transfer fluid up to 650F
– Single and Multi-Zone Configurations
– Pumping Capacity up to 120GPM
– Low Watt Density Heating
– All-welded construction
– Mag-drive pumps
– Explosion Proof Systems

COMBINATION SYSTEMS

Cooling Capacity: -60F
Heating Capacity: +400F

For applications that require a combination of temperature control at both ends of the cooling & heating spectrum.

Are you in one of the following industries and have a process that requires both cooling and heating?

  • Chemical
  • Pharmaceutical
  • Oil & Gas
  • Testing Laboratories

CONTAINERIZED SYSTEMS

  • Fully customized skids installed into standard or modified ISO containers
  • Furnished with lighting, ventilation, leak detection, and heating as standard
  • Custom options such as doorways, lag-downs equipment arrangement, special ventilation, paint, or alarm indication are all available

Great for applications that include:

  • Chillers (primarily water cooled)
  • Cooling tower pumping systems
  • Chiller pumping systems
  • Heating systems

If floor space is limited, maybe it’s time to consider a containerized outdoor system!

PROCESS PUMP AND TANK SYSTEMS

  • Chiller pumping systems ranging from a simple tank with a single pump to a 1200-gallon hot/cold tank with multiple pumps.
  • Hot/cold tanks are fitted with two pumps, one for the process and one to recirculate to the fluid cooler. The standby pump option is piped to serve as a backup for the process or recirculating pump.
  • Capacities range from 25 to 200 nominal tons.
  • Tempest also designs and manufactures specialized equipment for non-standard applications.

Who We Are

 We are ENGINEERING | MANUFACTURING | SERVICE

Engineering Services

Tempest Team
We are engineering and innovation – challenging the status quo by aggressively taking on projects others can’t. Tempest Engineering has developed a 6-Step FOCESS engineering approach that is applied to all projects.

6-Step FOCESS Engineering Approach

FACTS – Comprehensive understanding of the application, process and equipment specifications

OBJECTIVES – Complete understanding of the business and process objectives to be met

CHALLENGES – Complete understanding of the business and process challenges/concerns

ENGINEERING – Concept Engineering, Value Engineer, Design for manufacturability, reliability, and serviceability

SYSTEM BUILD & TEST – 100% built and tested to the engineered functional and performance specifications

STARTUP & SERVICE – Installation, startup, and full service 24/7 coverage

Manufacturing

We are manufacturing – Our facility and capabilities allow us to focus on bringing innovation into our designing, building, testing, and delivering of Tempest systems.
  • 70,000 sq.ft. manufacturing facility
  • (4) 15-ton overhead bridge cranes
  • 28 ft.under hook
  • (8) 1-ton jib cranes
  • UL 508 panel shop
  • Equipment test department
  • Compressor rebuild shop
  • ISO9001:2008 best practices facility
Manufacturing Facility

Service and Parts

Service and Parts
We are service – it’s part of our heritage, from demolition of your existing system to the installation, startup and service of your new Tempest system, we can do it all.
  • Mechanical & Electrical Engineering Services
  • Installation & Start-up Services
  • General Troubleshooting & Repair Services
  • Rebuild/Remanufacturing Services
  • Emergency Repair Service: 24/7
  • Preventative Maintenance Programs
  • Service of many OEM makes & models
  • Customized Programs to you needs
